Deutsche Hydrapro in New Zealand

Electric over hydraulic brake actuators for trailers

Fast, strong and consistent disc braking for boat trailers, car carriers, plant trailers and caravans. Your electric brake controller signals the actuator, and it delivers hydraulic pressure to the disc brakes in a fraction of a second.

See the range Talk to us about your trailer
Made in Australia · distributed and supported in NZ by TowPro Group
Deutsche Hydrapro Alpha G1600 electric over hydraulic brake actuator
1600 PSIMaximum output
1000 PSI in <0.2 sRapid brake response
IP67Water-ingress protection
2-year warrantyBacked in NZ by TowPro
How it works

Electric control, hydraulic stopping power

Electric drum brakes are fine on lighter trailers. Heavier loads, and trailers that get dunked in salt water, are better off with hydraulic disc brakes. An EOH actuator lets you run disc brakes off the electric brake controller you already have.

You brake

Your in-cab electric brake controller sends its normal signal down the trailer plug.

The actuator responds

A DC motor and pump in the actuator build hydraulic pressure in proportion to that signal.

The discs clamp

Brake fluid pressure applies the trailer's disc brakes, smoothly and consistently.

Why Deutsche Hydrapro

Built for harsh conditions

Built-in compatibility adapter

Works with standard electric brake controllers without an external adapter, for plug-and-play simplicity.

Consistent, proportional braking

A wide proportional braking range and consistent force at maximum pressure, with high braking force for the power drawn.

Sealed against salt and grime

Anodised T6 extruded alloy housing, an independently sealed fluid tank and a conformal-coated circuit board. IP67 rated.

Deutsche Hydrapro Alpha G1600 brake actuator
The actuator

Alpha G1600 Brake Actuator

The 1600 PSI electric over hydraulic actuator for disc-braked trailers, from single axle through to quad axle.

  • Up to 1600 PSI, reaching 1000 PSI in under 0.2 seconds
  • Built-in compatibility adapter
  • Weatherproof anodised alloy housing and sealed fluid tank
  • 12V, on a circuit of at least 30 amps

$1,528.99 NZD incl. GST

Shop the G1600

Optimised for disc brakes. Uses DOT 3 or DOT 4 brake fluid only, not Super DOT 4 or DOT 4+.

Deutsche Hydrapro Alpha G1600 actuator kit with integrated breakaway system
Complete kit

Alpha G1600 Kit with Integrated Breakaway

Everything you need in one box: the actuator plus a breakaway system that applies the brakes if the trailer ever separates from the tow vehicle.

  • Alpha brake actuator
  • Breakaway junction box with charge status indicator
  • 10Ah backup battery with integrated smart charger
  • Pull switch with 48" leads and plastic-coated stainless pull cable
  • Three mounting options to suit your trailer

$2,199.00 NZD incl. GST

Shop the kit
Alpha G1600 at a glance

Specifications

ApplicationDisc brakes, single to quad axle
MountingTrailer-mounted
Power supply12V DC, 30 A min. circuit
Current draw18–24 A at full pressure
Hydraulic port3/16" inverted flare
Brake fluidDOT 3 or DOT 4
Dimensions255 × 152 × 90 mm
Wiring4-wire, incl. breakaway

Full wiring details and recommended wire gauges are in the product manual and wiring diagram below.

Installer resources

Manuals, wiring and compatibility

These open on the Deutsche Hydrapro website in a new tab.

Product manualInstallation, bleeding and set-upOpen PDF ↗ Wiring diagramPower, controller, breakaway and groundOpen PDF ↗ Troubleshooting guideCommon issues and fixesOpen PDF ↗ Voltage / PSI drop calculatorCheck your wiring run before you installOpen ↗ Controller compatibilityFactory in-cab controllers that need an adapterOpen ↗ VideosProduct and install videos on YouTubeOpen ↗
The Deutsche Hydrapro story

Why an Australian company has a German name

Founder Dr Dale Hynd grew up around the Australian trailer industry. While studying in the UK he found the brake actuators on offer unreliable, so he started designing his own pump. When a respected European hydraulics manufacturer wouldn't take his calls, he and a group of fellow engineers flew to its headquarters and waited in the lobby until they got a meeting.

The manufacturer agreed to build the pump, and Deutsche Hydrapro was born, named as a nod to that partnership and its 90-plus years of hydraulic engineering. The company is based in Victoria, and its actuators are sold across Australia, New Zealand and North America. In New Zealand, Deutsche Hydrapro is distributed and supported by TowPro Group.

Backed here in New Zealand

Sold, supported and fitted by TowPro

TowPro Group is the New Zealand distributor for Deutsche Hydrapro. Our TowPro Trailers workshop in Waerenga builds and repairs trailers, brakes included, so we know these systems from the workshop floor.

Fitting and brake work

Need an actuator fitted or a trailer converted to disc brakes? Our workshop can quote it. TowPro Trailers →

Compatibility check

Tell us your tow vehicle and brake controller and we'll confirm it will work before you buy. Ask us →

Talk to us

Trailer builders and dealer enquiries welcome. +64 27 786 9776 · info@towprogroup.co.nz

Common questions

Good to know

Does it work with my brake controller?

The actuator has a built-in compatibility adapter and works with standard electric brake controllers. Some factory-fitted in-cab controllers, mainly on certain Ford, RAM and GM models, need an extra adapter to detect an EOH system. Check the compatibility list above, or ask us before you buy.

Can I use it with drum brakes?

The Alpha G1600 is optimised for hydraulic disc brakes. If your trailer has electric drum brakes now, talk to us about converting to discs.

What brake fluid does it use?

DOT 3 or DOT 4 only. Don't use Super DOT 4 or DOT 4+.

What power supply does it need?

12V DC on a circuit of at least 30 amps. It draws 18 to 24 amps at full pressure, so heavy-gauge wiring is needed for the power and ground. See the wiring diagram and the voltage drop calculator above.

What warranty does it have?

A 2-year warranty from Deutsche Hydrapro. Claims in New Zealand are handled through TowPro.

Superior braking power for your trailer

Shop the Alpha G1600, or talk to our workshop about fitting and conversions.

Shop Deutsche HydraproContact TowPro
